CARBON STEEL H BEAM ASTM A36 HM yog ib feem ntawm kev lag luam thiab kev ua haujlwm siab nrog ntau qhov chaw faib khoom zoo dua thiab tsim nyog lub zog hnyav piv. Nws yog lub npe vim nws seem yog tib yam li tsab ntawv Askiv "H". Vim tias txhua qhov ntawm H-section steel yog teem rau ntawm txoj cai kaum, H-section steel muaj qhov zoo ntawm kev khoov muaj zog, kev tsim kho yooj yim, txuag nqi thiab lub teeb nyhav hauv txhua qhov kev qhia, thiab tau siv dav.
| Qib hlau | Cov qauv | Cov pa roj carbon, max,% | Manganese,% | Phosphorus, max,% | Sulfur, max,% | Silicon,% |
|---|---|---|---|---|---|---|
| A36 | Hlau seem | 0.26 | -- | 0.04 | 0.05 | Tsawg dua lossis sib npaug rau 0.40 |
Nco tseg: Cov ntsiab lus tooj liab muaj nyob rau thaum koj xaj xaj.
| Qib hlau | Cov qauv | Tensile zog, ksi [MPa] | Yield point, min, ksi [MPa] | Elongation hauv 8 nti [200 mm], min, % | Elongation hauv 2 nti [50 mm], min, % |
|---|---|---|---|---|---|
| A36 | Hlau seem | 58 - 80 [400 - 550] | 36 [250] | 20 | 21 |
CARBON STEEL H BEAM ASTM A36 HMtau dav siv thoob plaws hauv kev tsim kho kev lag luam thaum txhawb nqa hnyav yuav tsum tau ua. Feem ntau hu ua "H" Beam vim nws cov duab, kab teeb muab kev txhawb nqa zoo thaum siv kab rov tav lossis sawv ua ke. Muaj nyob rau hauv ob configurations, qhov nrov tshaj plaws yog covWide Flange Steel Beamaka H Beam los yog W Beam nrog tsis-tapered flanges. Cov nqaj zoo li no muaj qhov dav dav ntxiv rau cov kab rov tav ntxiv, ua rau nws zoo tagnrho rau lub ntuj scrapers lossis raws li lub tsev beam, nrog rau cov nqaj nqaj hlau, tsheb thauj khoom, platforms, thiab lwm yam.
