S960QL yog qib siab -lub zog steel qib uas txhais los ntawm European tus qauv EN 10025-6. Nws yog cov khoom siv quenched thiab tempered tsim rau kev thauj khoom- cov ntaub ntawv siv cov kabmob uas yuav tsum tau muaj kev sib xyaw ua ke ntawm cov khoom muaj zog thiab qhov kub thiab txias.
Lub npe tawg
S:Cov qauv hlau.
960:Yam tsawg kawg nkaus yield zog ntawm 960 MPa (rau thicknesses tsawg dua los yog sib npaug li 50 mm).
Q:Quenched thiab tempered.
L:Kev ntsuas kub tsawg, tshwj xeeb ntawm -40 degree.
Ntsiab Specifications
| Feature | Paub meej |
|---|---|
| Khoom Naj Npawb | 1.8933 |
| Txuj | TS EN 10025-6 |
| Mechanical Properties | High yield zog (min 960 MPa) thiab siab cuam tshuam toughness (tsawg kawg 40 J ntawm -40 degree) |
| Kwv yees qhov sib npaug | ASTM A514 thiab IS 2062 (Indian Standard). |
| Cov npe lag luam | Strenx 960 (SSAB), Amstrong Ultra 960QL (ArcelorMittal), thiab Dillimax 960 (Dillinger). |
Cov ntawv thov tseem ceeb
Vim nws lub zog zoo tshaj - rau - qhov hnyav piv, nws yog siv los txo qhov hnyav ntawm cov qauv hnyav thaum tswj kev nyab xeeb:
Lifting thiab tuav:Telescopic cranes, mobile cranes, thiab cov khoom nqa nqa.
Kev thauj mus los:Trailer chassis, hnyav- lub luag haujlwm ntawm lub tsheb, thiab cov qauv choj.
Mining thiab Earthmoving:Cov thoob rau excavators, pob tseg tsheb lub cev, thiab kev txhawb nqa mining.
Zog:Offshore cov qauv thiab cov khoom siv rau cua zog.
Rhiav Properties
Weldability:Zoo weldability, txawm tias rhiab heev rau cov cua kub ntau dhau, uas tuaj yeem ua rau qhov kub ntxhov (HAZ).
Formability:Khoov tau zoo heev thiab qhov zoo ntawm qhov chaw, tso cai rau kev ua kom txias txias - ua haujlwm.
S960QL feem ntau siv nyob qhov twg?
S960QL yog ib qho ultra-high-strength, low-temperature tawv steel siv nyob rau hauv huab, hnyav-tseem ceeb daim ntaub ntawv uas cov Cheebtsam yuav tsum muaj kev ntseeg siab nyob rau hauv cov huab cua txias (txog -40 degree). Nws siv yog txwv rau kev tsim kho kom zoo, kev nyab xeeb tseem ceeb ntawm cov khoom siv vim nws tus nqi siab, kev sib tw ntawm kev tsim, thiab kev tsim qauv nruj.
Qhov Chaw Ua Haujlwm Tseem Ceeb:
1. Advanced Heavy Lifting & Cov Khoom Siv
Ultra-High-Capacity Mobile Crane Booms: Cov ntu tseem ceeb ntawm telescopic thiab lattice booms rau qhov loj tshaj plaws txhua qhov av thiab crawler cranes, qhov twg qhov hnyav txo ncaj qha nce lifting peev thiab ncav cuag.
Offshore & Shipboard Cranes: Boom caj npab, jibs, thiab cov txheej txheem ntawm cov nkoj thauj khoom thiab cov chaw ua haujlwm hauv hiav txwv txias.
2. Kev ua haujlwm siab mining & khoom hnyav
Drill Rig Masts & Shovel Arms: Cov khoom tseem ceeb ntawm kev ntxhov siab nyob rau hauv cov mining loj xyaum thiab excavators siv nyob rau hauv cov cheeb tsam txias (xws li, Canada, Scandinavia, Siberia).
Haul Truck Chassis & Ncej: Lub tswv yim yuag-txuag cov ntsiab lus hauv ultra-class mining tsheb thauj khoom kom ua tiav cov khoom thauj.
3. Kev Tiv Thaiv Tshwj Xeeb & Aerospace
Tub Rog Lub Tsheb Chassis & Armor Support Structures: Rau lub teeb yuag, siab-mobility tactical tsheb tsim los rau huab cua txias lossis Arctic ua haujlwm.
Aerospace Ground Support Equipment: Heavy-duty lifts thav duab thiab towbars rau aircraft tuav nyob rau hauv cov huab cua txias.
4. Xav tau Offshore & Zog Cov Qauv
Offshore Mooring & Lifting Cheebtsam: Cov kev sib txuas tseem ceeb, cov pins, thiab cov khoom sib txuas hauv cov roj dej sib sib zog nqus & roj platforms raug rau qhov chaw txias marine.
Cov Cuab Yeej Tshwj Xeeb Cov Cuab Yeej Siv Hluav Taws Xob: Qhov chaw muaj kev ntxhov siab siab rau cov hauv paus ntug dej hiav txwv cua turbine (piv txwv li, cov khoom hloov pauv, flange reinforcements) nyob rau hauv cov cheeb tsam txias xws li North Hiav Txwv lossis Baltic Hiav Txwv.
5. High-Risk Racing & Tsheb thauj mus los
High-Performance Racing Tsheb Chassis & Roll Cages (nyob rau hauv sab saum toj-tier motorsports qhov twg FIA cov cai tso cai ultra-high-lub zog steels).
Tshwj xeeb Heavy Thauj Trailers rau kev thauj khoom txawv txav uas qhov hnyav txuag nce lub peev xwm thauj khoom.
Vim li cas S960QL raug xaiv (vs. Qib qis zog):
Txo qhov hnyav tshaj plaws: Nws 960 MPa yield zog tso cai rau qhov thinnest tau seem, txo qhov hnyav thaum tuav lub peev xwm thauj khoom - tseem ceeb rau cov khoom siv txawb uas txhua kilogram khaws cia txhim kho kev ua haujlwm.
Low-Temperature Assurance: Daim ntawv pov thawj "QL" lav qhov cuam tshuam rau qhov hnyav ntawm -40 degree, ua kom muaj kev tiv thaiv kev tawg hauv cov huab cua txias.
Space Efficiency: Ua kom muaj kev sib txuam ntau dua, muaj peev xwm ntau dua.
1. S960QL steel yog dab tsi?
S960QL yog ib qho ultra- siab - lub zog quenched thiab tempered structural steel nrog qhov tsawg kawg nkaus lub zog ntawm 960 MPa, tau ntawv pov thawj rau qhov zoo cuam tshuam toughness ntawm qis kub mus rau -40℃.
2. S960QL feem ntau siv nyob qhov twg?
Nws yog siv rau hauv qhov hnyav hnyav- cov ntawv thov tseem ceeb xws li kev tshaj xov tooj ntawm tes crane booms, siab - tsheb tub rog kev ua tau zoo, cov khoom nqa tawm sab nraud, thiab cov cuab yeej tshwj xeeb mining ua haujlwm hauv huab cua txias.
3. S960QL txawv ntawm S960Q li cas?
S960QL yog sub-qib nrog lav qhov cuam tshuam qhov hnyav ntawm -40 degree, thaum tus qauv S960Q feem ntau yog ntsuas kub siab (feem ntau -20℃lossis 0℃).
4. Cov txheej txheem vuam dab tsi yuav tsum tau ua rau S960QL?
Vuam S960QL yuav tsum nruj preheating (150-250 degree), qis- hydrogen consumables, tswj cov cua sov input, thiab feem ntau tom qab vuam cua sov kev kho mob kom tsis txhob tawg thiab khaws toughness.
5. Cov tshuaj muaj pes tsawg leeg ntawm S960QL yog dab tsi?
Nws muaj cov pa roj carbon tsawg nrog micro- alloys (niobium, vanadium, titanium, boron) thiab cov khoom xws li npib tsib xee, chromium, thiab molybdenum rau hardenability thiab qis- kub toughness.
6. S960QL puas tuaj yeem ua tau yooj yim?
Tsis yog, machining S960QL yog qhov nyuaj heev vim nws qhov hardness siab; nws yuav tsum muaj cov cuab yeej zoo carbide, siab -siab coolant, rigid setups, thiab optimized parameters.
7. Cov qauv twg siv rau S960QL steel?
Nws yog tswj hwm los ntawm European tus qauv EN 10025-6 rau quenched thiab tempered siab -lub zog steels, nrog rau ntxiv toughness yuav tsum tau rau "QL" sub-qib.
8. Puas yog S960QL corrosion resistant?
Tsis yog, S960QL tsis yog corrosion-tiv taus thiab yuav tsum muaj cov txheej txheem tiv thaiv (xws li, pleev xim, galvanizing) siv rau hauv qhov chaw corrosive lossis raug.
9. Tus nqi ntau ntawm S960QL steel phaj yog dab tsi?
S960QL yog kim heev, feem ntau yog li ntawm € 4,500 txog € 9, 000+ ib tuj, nyob ntawm thickness, ntau, thiab ntawv pov thawj.
Tag nrho cov specification thiab cov ntsiab lus muaj nyob rau ntawm kev thov. Cov ntaub ntawv saum toj no yog muab rau kev taw qhia nkaus xwb. Rau kev tsim tshwj xeeb thov hu rau peb cov neeg ua haujlwm muag khoom.
