Dab tsi yog Solution- kho Mn13 steel phaj
Kev daws- kho Mn13 steel phajyog ib qho siab -manganese hnav- cov phaj hlau uas ua los ntawm kev kub siab - cov txheej txheem kev kho cua sov (feem ntau yog 1000-1100℃tom qab dej quenching).
Cov txheej txheem no dissolves carbides rov qab mus rau hauv lub austenite matrix, tsim ib tug ruaj khov -theem austenitic qauv nrog zoo heev toughness thiab tej yam kuj. Piv nrog cov pa roj carbon zoo tib yam, Mn13 steel tuaj yeem xa 3-5 npaug ntawm lub neej kev pabcuam siab dua nyob rau hauv kev cuam tshuam hnyav thiab hnav tsis zoo, nyob ntawm qhov chaw ua haujlwm.
Tom qab kev daws teeb meem, Mn13 steel phaj nthuav tawm kev ua haujlwm tshwj xeeb- muaj peev xwm hardening. Nws qhov pib hardness kuj tsawg, feem ntau nyob ib ncig ntawm 180-220 HB, tab sis nyob rau hauv muaj zog cuam tshuam thiab nruam puas, qhov tawv hardness tuaj yeem nce mus rau 450-550 HB, thiab nyob rau hauv huab cua ua hauj lwm tej zaum yuav txawm ntau tshaj qhov no hauv zos.
Qhov kev ua haujlwm muaj zog no- cov lus teb nyuaj tso cai rau cov khoom siv txuas ntxiv ntxiv dag zog thaum lub sijhawm ua haujlwm thaum lub hauv paus tseem tawv thiab ductile. Tsis zoo li cov pa hlau uas niaj hnub hnav, Mn13 yuav nyuaj dua thaum nws siv, txhim kho nws cov kev tiv thaiv rau kev cuam tshuam thiab zawv zawg hnav.
Ua tsaug rau qhov tshwj xeeb "tus kheej- hardening" tus cwj pwm, kev daws teeb meem- kho Mn13 steel phaj yog dav siv nyob rau hauv mining machinery, crusher liners, hoppers, chutes, excavator buckets, thiab lwm yam siab - cuam tshuam ib puag ncig hnav.
Hauv kev siv cov tswv yim, nws tuaj yeem txo cov nqi kho thiab hloov pauv li ntawm 40-60% piv nrog cov pa roj carbon monoxide ib txwm muaj lossis qis dua - alloy hnav- cov hlau tsis muaj zog, ua rau nws raug nqi ntau heev - kev daws teeb meem zoo rau kev lag luam hnyav -.
GNEE muaj ntau dua 18 xyoo ntawm kev tsim khoom thiab xa tawm cov kev paub hauv kev hnav- cov khoom siv hlau tiv taus thiab tau muabtshuaj- kho Mn13 steel phajrau cov tswv lag luam mining, cement nroj tsuag, steel mills, thiab cov khoom siv hnyav hauv ntau tshaj 80 lub teb chaws thoob ntiaj teb.
Peb cov Mn13 steel phaj tau dav siv hauv siab - cuam tshuam thiab siab - kev puas tsuaj xws li crusher liners, hoppers, chutes, thiab excavator hnav qhov chaw. Peb txhawb nqa ob qho tib si loj - nplai engineering tej yaam num thiab kev txiav txim me me, nrog rau qhov tsawg kawg nkaus txiav txim kom muaj nuj nqis (MOQ) tsawg li ib thooj.
Hu rau tam sim no kom tau txais Mn13 siab manganese steel phaj Quote
Tsis tas li ntawd, tag nrho cov kev daws teeb meem -kho Mn13 steel daim hlau raug nruj ua ntej- kev tshuaj xyuas cov khoom xa tuaj, suav nrog 100% kev tshuaj xyuas kev tshuaj xyuas, PMI (Positive Material Identification) tshuaj ntsuam xyuas, kuaj ultrasonic (UT), thiab kev tshuaj xyuas flatness.
Txhua lub phaj yog muab nrog EN 10204 3.2 Daim Ntawv Pov Thawj Zeb Xeem (MTC), thiab peb cov khoom tau lees paub los ntawm ISO 9001, SGS, thiab BV thib peb- tog neeg soj ntsuam cov tub ceev xwm, kom ntseeg tau tias muaj kev ua tau zoo thiab txhim khu kev qha rau cov ntawv thov hnav tseem ceeb.
Kev daws- kho Mn13 Steel Phaj Specification
| Yam khoom | Specification |
|---|---|
| Khoom npe | Kev daws- kho Mn13 Steel Phaj |
| Khoom Qib | Mn13 / Hadfield Steel / X120Mn12 / ASTM A128 Qib B |
| Txuj | GB / T 5680 / ASTM A128 / DIN 1.3401 |
| Yam khoom | Kub Rolled Hnav-resistant Plate / Austenitic Steel Phaj |
| Thickness Ntau | 3 hli-120mm |
| Dav Ntau | 1000mm - 3000mm |
| Ntev Ntau | 2000mm - 12000mm (los yog customized txiav) |
| Surface condition | Kub dov / Txhaj blasted / Pickled (yeem) |
| Kev tsim khoom | Melting → Kub Rolling → Tshuaj kho (1000-1100 degree) → Dej quenching → Straightening |
| Kev Xa Khoom | Kev daws teeb meem-kho & dej quenched (tag nrho austenitic qauv) |
| Pib Hardness | 180-220 HWB |
| Ua haujlwm -Hardened Hardness | 450-550 HBW (nyob ntawm kev ua haujlwm) |
| Daim ntawv pov thawj | ISO 9001 / SGS / BV / EN 10204 3.1 lossis 3.2 |
| Kev tshuaj xyuas | Kev kuaj PMI, kuaj ultrasonic (UT), kuaj hardness, ntsuas qhov ntev |
| Ntim | Waterproof ntawv, yas zaj duab xis, steel straps, ntoo pallets, seaworthy export packing |
Kev daws- kho Mn13 Steel Plate Chemical Composition
| Lub ntsiab | Cov ntsiab lus (%) |
|---|---|
| Cov pa roj carbon (C) | 1.00 – 1.30 |
| Manganese (Mn) | 11.00 – 14.00 |
| Silicon (Si) | 0.30 – 1.00 |
| Phosphorus (P) | Tsawg dua lossis sib npaug li 0.060 |
| Sulfur (S) | Tsawg dua lossis sib npaug li 0.050 |
| Chromium (Cr) | Tsawg dua lossis sib npaug li 1.00 |
| Nickel (Ni) | Tsawg dua lossis sib npaug li 1.00 |
| Hlau (Fe) | Balance (Tseem tshuav) |
Kev daws teeb meem- kho Mn13 Steel Plate Physical Properties
| Khoom | Tus nqi |
|---|---|
| Qhov ntom | 7.85 g / cm³ |
| Pib Hardness | 180-220 HWB |
| Ua haujlwm -Hardened Hardness | 450 - 550 HBW (mus txog siab dua nyob rau hauv kev cuam tshuam loj heev) |
| Tensile zog | 800 - 1000 MPa (tom qab ua hauj lwm hardening) |
| Yield zog | 350-450 MPa (kwv yees) |
| Elongation | 35 – 50% |
| Impact Toughness | Siab heev (zoo heev tiv taus hnyav hnyav loads) |
| Elastic Modulus | 190-210 GPa |
| Thermal conductivity | ~11 – 14 W/m·K |
| Kev Pabcuam Kub | Haum rau chav sov thiab qis - mus rau - nruab nrab kub hnav ib puag ncig |
Kev daws- kho Mn13 Steel Phaj Tolerance
| Yam khoom | Tolerance Range |
|---|---|
| Thickness kam rau ua | ±0.3 mm (≤10 mm) / ±0.5 mm (10–50 mm) / ±1.0 mm (>50 hli) |
| Dav Tolerance | 0 / +10 hli |
| Ntev Ntev | 0 / +15 hli (txiav- rau- qhov ntev) |
| Flatness kam rau ua | Tsawg dua los yog sib npaug li 5 hli ib 'meter' (nyob ntawm qhov tuab thiab kev kho cua sov) |
| Diagonal kam rau ua | Tsawg dua los yog sib npaug li 10 mm rau cov ntawv txheeb |
| Edge Condition Tolerance | Sheared / nplaim taws- txiav ntug tso cai, me ntsis irregularity txais tau |
| Deviation saum npoo | Me me dov cov cim tso cai, tsis muaj kab nrib pleb, tsis muaj lamination defects |
| Nyhav Tolerance | ± 5% (rau qhov ntsuas qhov hnyav) |
Dab tsi yog qhov txawv ntawm A36 thiab Mn13 steel phaj?
Mn13 steel phaj muaj li 3-5 npaug ntawm lub neej kev pab cuam ntev dua li A36 carbon steel nyob rau hauv siab - cuam tshuam rau kev hnav, vim Mn13 ua haujlwm- hardens rau 450-550 HB, thaum A36 tseem nyob ntawm 120-160 HB uas tsis muaj kev ua haujlwm - muaj peev xwm hardening.
Dab tsi yog qhov txawv ntawm A36 thiab NM400 steel phaj?
Mn13 steel phaj zoo dua rau siab - cuam tshuam thiab kev poob siab hnyav, thiab tuaj yeem ncav cuag 450-550 HB tom qab ua haujlwm hardening, thaum NM400 muaj qhov nyuaj tas li ntawm 360-420 HB, yog li Mn13 tuaj yeem kav ntev li 1.5-3 zaug ntev dua NM400 hauv qhov muaj kev cuam tshuam qis dua 0, NM 2. abrasive hnav.
Daim ntawv thov kev daws teeb meem- kho Mn13 steel phaj
Cov khoom siv mining thiab quarrying: crusher liners, lub puab tsaig daim hlau, lub khob hliav qab crusher qhov chaw, thiab cov phaj cuam tshuam.
Cement thiab siv tshuab: hopper liners, chute liners, thiab hnyav -cov haujlwm conveyor hnav daim hlau.
Metallurgical thiab steel kev lag luam: sinter cog liners, steel zeb hoppers, thiab slag tuav cov cuab yeej.
Heavy-cov khoom siv ua haujlwm: cov thoob excavator, cov tshuab bulldozer, thiab cov khoom siv thauj khoom hnav.
Railway thiab chaw nres nkoj systems: wagon liners, unloading chutes, thiab bulk khoom tuav systems.
Mn13 Steel Phaj Nqe Lus Qhia
| Yam khoom | Specification |
|---|---|
| Khoom | Mn13 Hlau Phaj (Hadfield Steel / X120Mn12) |
| Nqe Ntau (FOB Tuam Tshoj) | USD 1,200 - 2,500 / ton |
| Nqe Unit | Ib metric tons (MT) |
| Thickness cuam tshuam | 3-20mm: qis qis / 50-120mm: ntau dua |
| MOQ cuam tshuam | Kev txiav txim ntau: tus nqi qis / Me me: tus nqi siab dua |
| Kev kho cua sov | Solution-kho & dej quenched: tus nqi siab dua |
| Tus nqi ua haujlwm | Txiav, machining, thiab ntug npaj nce nqi |
| Surface condition | Kub dov txheem: puag tus nqi / txhaj tshuaj blasted los yog machined: siab dua |
| Kev Ua Lag Luam | Manganese nqi, steel zeb tso zis, shipping nqi |
| Tus nqi txheeb ze vs Carbon Steel | ~ 2–4 × siab dua A36/Q235 |
| Tus nqi txheeb ze vs NM400 | Zoo sib xws los yog me ntsis siab dua nyob ntawm qhov mob |
Yog hais tias koj muaj tej yam yuav tsum tau qhov project rauMn13 steel phaj, peb txais tos koj nug thiab xaj. GNEE tuav cov khoom ruaj khov ntawm kev daws teeb meem- kho Mn13 steel daim hlau nrog cov khoom lag luam txhim khu kev qha rau kev xa khoom sai.
Hu rau tam sim no kom tau txais Mn13 siab manganese steel phaj Tshuag
Peb muab cov kev pabcuam customized suav nrog kev txiav- rau- qhov loj me, kev npaj ntug, thiab kev ua tiav saum npoo xws li kub dov, tua blasted, thiab machined tej yam kev mob kom tau raws li cov kev lag luam sib txawv.Quality Control of Mn13 Steel Plate
Kev kuaj:Tshuaj muaj pes tsawg leeg tsom xam, hardness test, tensile test, impact test, ultrasonic test (UT), dimensional inspection, flatness inspection, and visual inspection.
Tus nqi{0}} ntxiv cov kev pabcuam:Ib qho - nres kev ua raws li kev cai, suav nrog kev txiav - mus rau - qhov loj me, kev npaj ntug, theem, machining, thiab kev daws kev kho kom zoo raws li daim ntawv thov.
Ntim thiab Shipping ntawm Mn13 Steel Phaj
Ntim:Txhua qhov kev daws teeb meem- kho Mn13 steel phaj yog qhwv nrog cov ntawv tsis muaj dej thiab yas zaj duab xis, tom qab ntawd muab cov hlua khi ruaj khov. Sab nrauv yog ntxiv dag zog nrog ntoo pallets los yog crates kom muaj kev nyab xeeb thaum tuav thiab thoob ntiaj teb dej hiav txwv / huab cua thauj.
Kev sau npe:Txhua pob tau cim meej nrog tus lej xov tooj cua sov, qib khoom siv, qhov ntev, thiab cov txheej txheem kho cua sov kom paub meej tag nrho.
Lub sij hawm xa tuaj:Feem ntau 10-25 hnub ua haujlwm thaum tau txais cov nyiaj them ua ntej, raws li kev txiav txim kom muaj nuj nqis thiab kev ua raws li kev cai.
Shipping Method:Hiav txwv freight (FCL / LCL), huab cua freight, los yog multimodal thauj tailored rau cov neeg yuav tsum tau thiab qhov project ceev.
